GIGABYTE GeForce RTX 5060 D7 Low Profile 8G

The GIGABYTE GeForce RTX 5060 D7 Low Profile 8G graphics card with 8 GB of RAM is exactly what you're looking for, with a clock speed of 28000 MHz. With this amount of RAM, the 128Bit bus, and a core speed of 2280 MHz The graphics card has the PCI Express x16 5,0 interface, and it has 4 ports for the connection of a screen. For this graphics card, the manufacturer chose the DisplayPort 2,1b and HDMI 2,1b interface for the connection of a monitor. The active cooling on this graphics card delivers very low temperatures, even under a heavy load.

Graphics Card GIGABYTE GeForce RTX 5060 D7 Low Profile 8G ...
Graphics Card GIGABYTE GeForce RTX 5060 D7 Low Profile 8G ...

GIGABYTE GeForce RTX 5060 D7 Low Profile 8G Gaming Graphics Card Key Features

  • Graphics card has RTX 5060 graphics chip with 4 nm production technology
  • GIGABYTE GeForce RTX 5060 D7 Low Profile 8G graphics card will connect to 4 screens
  • Thermal design power: 145 W
  • Recommended PSU performance of at least: 550 W
  • VR support for hardcore gamers
  • NVIDIA GeForce RTX 5060 graphics card random access memory: 8 GB
  • Graphics card cooling tech: Active
  • Graphics card display port type: DisplayPort 2,1b and HDMI 2,1b

Active cooling, such as that, which is found in this graphics card, is widely used mainly because it's a safe and proven way to keep the temperature low. The Dual-slot cooling system on this graphics card features 3 fans and matches its cooling output to the current load.

Graphics Card GIGABYTE GeForce RTX 5060 D7 Low Profile 8G ...

Specifications

Dimensions

Width 182 mm
Height 36 mm
Depth 69 mm

Chip

Chip manufacturer NVIDIA GeForce
Model designation RTX 5060
Graphics processor GB206
Chip architecture Blackwell
Number of stream processors 3,840×
Production technology 4 nm

Performance & usage

Use Game playing

Memory

VRAM capacity 8 GB
Memory type GDDR7
Bus width 128-Bit

Frequency

Core frequency 2,280 MHz
Core clock speed (Boost clock) 2,497 MHz
Memory frequency 28,000 MHz (28 GHz)
Effective memory clock (bandwidth) 28 Gbps

Interface

PC connection PCI Express x16 5.0
Bus interface PCIe 5.0 x8
Monitor connection DisplayPort 2.1b, HDMI 2.1b

Technology

Special graphics card features NVIDIA DLSS 4.0
DirectX version 12 Ultimate

Cooling system

Cooling type Active
Cooling size Dual-slot
number of fans 3 ×

Consumption

TDP 145 W
Code:  EGr56l2
