Type
Switch type
Managed, Centrally controlled by controller
Design
Rack, Desktop
Use
Company
Functions
Functions
Auto-MDI/MDIX, Auto-negotiation, Port mirroring
Switching layer
L2
Advanced network functions
QoS (Quality of Service), VLAN, Static line aggregation, Q-in-Q, LACP line aggregation
Management and security
DoS prevention, Port Security, 802.1X authentication, Network loop detection, ACL
Functions for camera systems
Priority mode
Ports
RJ-45
8 ×
SFP+
2 ×
LAN port transmission speed
Number of LAN ports with 2.5 Gbit speed
8
Number of LAN ports with 10 Gbit speed
2
Routing
Features
Power Supply
From the network
Maximum number of VLANs
4,096 ×
Features
IPv6 Ready
Speed
Switching capacity
80 Gb/s
Packet capacity (64B packets, in million of packets)
59.52 Mpps
Dimensions
Width
294 mm
Height
44 mm
Depth
180 mm
Frame width
482.6 mm
Material
Body material
Metal
Operating temperature
Minimum operating temperature
0 °C
Maximum operating temperature
50 °C
Weight
Weight
1,310 g
Power outlet type
Country
Czechia, Slovakia, Hungary, Germany, Russia, Austria, Croatia, France, Poland, Romania, Slovenia
