Type
Switch type
Managed
Design
Desktop
Use
Home, Company
Functions
Functions
PoE
Switching layer
L4
Advanced network functions
QoS (Quality of Service), VLAN, VPN
Management and security
Firewall
Functions for camera systems
Isolation mode
Ports
RJ-45
1 ×
SFP+
4 ×
LAN port transmission speed
Number of LAN ports with 100 Mbit speed
0
Number of LAN ports with 1 Gbit speed
1
Number of LAN ports with 5 Gbit speed
0
PoE properties
PoE standard
802.3af (PoE), 802.3at (PoE+)
Performance
18 W
Number of PoE ports
1 ×
Routing
Routing
Static routing, RIP, BGP, VRRP, IS-IS
Features
Power Supply
From the network, PoE
Maximum number of VLANs
999 ×
Features
IPv6 Ready
Speed
Switching capacity
82 Gb/s
Packet capacity (64B packets, in million of packets)
61 Mpps
Dimensions
Width
141 mm
Height
28 mm
Depth
115 mm
Material
Body material
Metal
Operating temperature
Minimum operating temperature
-40 °C
Maximum operating temperature
70 °C
Weight
Weight
800 g
